HV3-5 Assemblies - 513994
Item Code: 33-OHHV3-5
Description
Description
22kV Small Delta Construction 3-5
Choose required options for pole length/pole steps, crossarm, kingbolt and conductor. Item code will change once all correct options are selected.
The M12 bolt length supplied with this kit, to suit the pole top bracket, is equal to the length of the king bolt less the width of the crossarm
** THE FOLLOWING ITEMS ARE NOT INCLUDED:
Item 1: Timber Pole (Quoted on request)
Item 15: Tie Wire
** All hardwood crossarms are supplied as undrilled
A 2100mm crossarm is to be used as the default crossarm while a 2700mm crossarm is used where additional mid span separation is required.
Ausgrid Drawing No. 513994
**These assemblies are picked and packed from components that are normally in stock.
Contact us if a turnaround of less than 1-2 weeks is required to meet your schedule.
