PEC Series - Pipe and fence post earthing clamps
Item Code: 08-PEC
Description
Description
PEC series of clamps are suitable for applications where an earth cable needs to be attached to a pipe or a fence post.
All clamps take a cable range from 16-120 sq mm and some are suitable for multiple cables.
Clamp bodies are made from copper alloy while U bolts, nuts and washers are stainless steel.
These clamps are also suitable for larger diameter earth rods.
Item Code will change once size is selected from dropdown
Data Sheet
PEC26 Drawing
PEC34 Drawing
PEC34D Drawing
PEC43 Drawing
PEC43D Drawing
PEC48D Drawing
PEC60T Drawing
All clamps take a cable range from 16-120 sq mm and some are suitable for multiple cables.
Clamp bodies are made from copper alloy while U bolts, nuts and washers are stainless steel.
These clamps are also suitable for larger diameter earth rods.
Item Code will change once size is selected from dropdown
Item Code | Pipe Size (mm) | No. of Cables | Cable Range | |
ID | OD | |||
08-PEC26 | 19 (¾") | 26 | 1 | 16-120 sq mm |
08-PEC34 | 25 (1") | 34 | 1 | 16-120 sq mm |
08-PEC34D | 25 (1") | 34 | 2 | 16-120 sq mm |
08-PEC43 | 32 (1 ¼") | 43 | 1 | 16-120 sq mm |
08-PEC43D | 32 (1 ¼") | 43 | 2 | 16-120 sq mm |
08-PEC48 | 38 (1 ½") | 48 | 1 | 16-120 sq mm |
08-PEC48D | 38 (1 ½") | 48 | 2 | 16-120 sq mm |
08-PEC60T | 51 (2") | 60 | 1, 2 or 3 | 16-120 sq mm |
