CPR13 - Copper plated earth rod 13mm dia 1400-2400mm L
Item Code: 08-CPR13
Description
Description
A range of lengths in copper plated earth rods including 1400mm, 1800mm and 2400mm long
Item Code will change to reflect the complete part number once length selected from dropdown
CPR13 Copper plated 13mm nominal diameter earth rods. Short circuit tested at 12kA for 1 second. Plating thickness is 250 microns minimum as required by AS3000. Earth rod clips and earth tags are available along with various clamps to suit different cable sizes.
Earth rods are easily joined for deeper driving using our taper fit slimline brass couplings which have an internal centralized stopper. Couplers (joiners) are designed to provide a strong permanent and secure end to end connection between earth rods.
Energex : 17321 (CPR1318)
Data Sheet
Drawing
Item Code will change to reflect the complete part number once length selected from dropdown
CPR13 Copper plated 13mm nominal diameter earth rods. Short circuit tested at 12kA for 1 second. Plating thickness is 250 microns minimum as required by AS3000. Earth rod clips and earth tags are available along with various clamps to suit different cable sizes.
| Item Code | Description | Size |
| 08-CPR1314 | Copper plated steel earth rod | 13mm dia x 1400mm long |
| 08-CPR1318 | Copper plated steel earth rod | 13mm dia x 1800mm long |
| 08-CPR1324 | Copper plated steel earth rod | 13mm dia x 2400mm long |
Earth rods are easily joined for deeper driving using our taper fit slimline brass couplings which have an internal centralized stopper. Couplers (joiners) are designed to provide a strong permanent and secure end to end connection between earth rods.
Energex : 17321 (CPR1318)
Data Sheet
Drawing
